Basement Stormwater Pump-Out Systems

Every basement in Sydney has a low point, and water will find it. The question is whether it leaves by gravity or by a pump.

Gravity is always the first choice, because a pipe that falls to the street has no moving parts and no power bill. But a basement floor sits below the street drainage, and the water that lands on the driveway ramp, seeps through the walls or drips off cars has nowhere to go but down. That water goes to a pump-out system, and the design of that system decides whether the basement stays dry in a storm.

What drains to the pump, and what does not

The first design decision is keeping the pump catchment as small as possible.

Roof water, balcony water and surface runoff from the site above the basement go to the street by gravity, through the on-site detention system where council requires one. None of it should be allowed to fall into the basement, because every litre that reaches the pump is a litre the pump has to lift and a litre that floods the car park if the pump fails.

What is left for the pump-out is usually rain falling on the open part of the driveway ramp, seepage through the basement walls and floor, and minor water inside the car park itself, such as wash down and drips off wet cars.

The ramp catchment is often the biggest of these, which is why the grated drain at the top of the ramp and the crest level at the boundary matter so much. The geometry is covered in [driveway grades and basement ramps](/blog/driveway-grades-and-basement-ramps).

The parts of the system

A pump-out pit at the lowest point of the basement, deep enough to hold the pumps and a working volume of water.

Two pumps, each sized to handle the design flow on its own, set up to alternate so both get used and both stay healthy. When one fails the other carries the load.

A storage volume that holds water for a period if both pumps stop, for example during a power outage in a storm. That storage can sit in the pit, in a tank, or in a dedicated part of the lowest slab.

A high-level alarm that tells someone when water is rising, wired to a place where it will actually be noticed.

A rising main and a boundary connection, usually discharging through a pit that breaks the pressure before the water enters the gravity system, so the pumped flow does not surcharge the street pipes.

Council stormwater policies across Sydney typically ask for each of these, and the exact storage period, pump arrangement and discharge point vary from one council to the next. The civil design has to follow the policy of the council the site sits in, not a generic template.

Groundwater is a different decision

Seepage from rain soaking down the back of the walls is one thing. A basement sitting in a groundwater table is another.

A drained basement that pumps groundwater out every day for the life of the building needs approvals that are often hard to get, and it can draw down the water table under the neighbours. In those conditions the usual answer is a tanked basement, built watertight and designed to resist the water pressure on its floor and walls. That design is set out in [basement tanking and hydrostatic uplift](/blog/basement-tanking-and-hydrostatic-uplift).

The geotechnical investigation tells you which situation you are in. It should be read before the pump-out is sized, not after.

Coordination with the structure

The pump-out pit is a hole in the lowest slab, and often in the deepest part of the excavation.

That puts it right where the shoring, the footings and the raft or pile caps are most congested. The pit wall may be a retaining wall in its own right, and its base may sit below the bulk excavation level, which means a local deeper dig with its own temporary support. When civil and structural are designed in separate offices, the pit is often drawn on top of a pile cap and found on site.

We design the pump-out as part of the basement, alongside the work described in [how we design basement structures in Sydney](/blog/how-we-design-basement-structures-sydney). The pit position, the slab falls to it, and the structural elements around it are fixed together, before anyone pours.

Maintenance is part of the design

A pump-out system is mechanical plant. It needs regular servicing, the pit needs cleaning of silt and debris, and the alarm needs testing.

So access matters. The pit lid needs to sit where a service technician can open it without moving cars, the pumps need to be removable without a confined space entry wherever possible, and the control panel needs to be somewhere dry. A system that is hard to maintain does not get maintained, and the first anyone hears about it is water across the bottom level.

The test

The test is a storm at two in the morning with the power out.

If the catchment is small, the storage holds, and the alarm tells someone before the water reaches the cars, the system has done its job. Design it for that night, and every other day takes care of itself.

ACSES provides civil engineering and basement drainage design across Sydney. Talk to us about a project.
